Dual Junction F Configuration 4 Ports Type N Circulator

Part Number	Frequency Range (MHz)		Insertion Loss		Isolation		Return Loss	Forward Power Peak/Avg	Rev Power	Package Size (mm)
	Low	High	P2-P1 P4-P3	P3-P2 P1-P4	P1-P2 P3-P4	P2-P3 P4-P1	All Ports	(W)		L	W
CR6101F	270	330	0.7	0.4	42	20	20	2500/250	250	100	50
CR6102F	328	406	0.7	0.4	42	20	20	2500/250	250	100	50
CR6108F	330	360	0.5	0.3	48	23	23	2500/250	250	90	45
CR6109F	350	380	0.5	0.3	48	23	23	2500/250	250	90	45
CR6110F	360	390	0.5	0.3	48	23	23	2500/250	250	90	45
CR6103F	380	470	0.7	0.4	42	20	20	2500/250	250	100	50
CR6111F	380	430	0.5	0.3	48	23	23	2500/250	250	90	45
CR6104F	400	500	0.7	0.4	42	20	20	2500/250	250	100	50
CR6112F	400	450	0.5	0.3	48	23	23	2500/250	250	90	45
CR6113F	415	455	0.5	0.3	48	23	23	2500/250	250	90	45
CR6114F	450	500	0.5	0.3	48	23	23	2500/250	250	90	45
CR6105F	470	570	0.7	0.4	42	20	20	2500/250	250	100	50
CR6115F	470	520	0.5	0.3	48	23	23	2500/250	250	90	45
CR6106F	512	698	0.9	0.5	40	19	19	2500/250	250	100	50
CR6116F	520	576	0.5	0.3	48	23	23	2500/250	250	90	45
CR6117F	576	638	0.5	0.3	48	23	23	2500/250	250	90	45
CR6107F	600	800	0.9	0.5	40	19	19	2500/250	250	100	50
CR6118F	600	750	0.7	0.4	48	23	23	2500/250	250	90	45
CR6120F	638	704	0.5	0.3	48	23	23	2500/250	250	76	38
CR6121F	698	806	0.7	0.4	48	23	23	2500/250	250	76	38
CR6119F	700	1000	0.9	0.5	40	19	19	2500/250	250	90	45
CR6122F	700	830	0.7	0.4	48	23	23	2500/250	250	76	38
CR6123F	700	850	0.7	0.4	48	23	23	2000/200	200	64	32
CR6201F	790	960	0.7	0.4	48	23	23	2000/200	200	64	32
CR6302F	850	1030	0.7	0.4	48	23	23	2000/200	200	64	32
CR6303F	900	1100	0.7	0.4	48	23	23	2000/200	200	64	32
CR6304F	960	1215	0.7	0.4	48	23	23	2000/200	200	64	32
CR6301F	1000	1400	0.9	0.5	40	19	19	2500/250	250	76	38
CR6305F	1000	1220	0.7	0.4	48	23	23	2000/200	200	64	32
CR6306F	1100	1300	0.7	0.4	48	23	23	2000/200	200	64	32
CR6307F	1200	1450	0.7	0.4	48	23	23	2000/200	200	64	32
CR6401F	1350	1850	0.7	0.4	40	19	19	2000/200	200	64	32
CR6402F	1400	1700	0.7	0.4	48	23	23	2000/200	200	64	32
CR6403F	1400	1600	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6404F	1500	1800	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6601F	1700	2100	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6701F	2000	2300	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6801F	2100	2600	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6802F	2300	2700	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6803F	2500	2900	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6804F	2700	3100	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6805F	2800	3300	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6806F	2900	3500	0.5	0.3	48	23	23	2000/200	200	50.8	25.4
CR6807F	3300	3800	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6808F	3400	4200	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6809F	3600	4300	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6901F	3900	4700	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6902F	4200	5200	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6903F	5000	6000	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6904F	5700	6800	0.5	0.3	48	23	23	500/50	50	50.8	25.4
CR6905F	6000	8000	0.5	0.3	48	23	23	500/50	50	50.8	25.4
