Dual Junction H Configuration 4 Ports Type N Circulator

Part Number	Frequency Range (MHz)		Isolation (dB)		Insertion Loss(dB)		Return Loss	Forward Power Peak/Avg	Rev Power	Package Size (mm)
	Low	High	P1-P2 P3-P4	P2-P3 P4-P1	P2-P1 P4-P3	P3-P2 P1-P4	All Ports	(W)		L	W
CR6101H	270	330	0.4	0.7	20	42	20	2500/250	250	50	100
CR6102H	328	406	0.4	0.7	20	42	20	2500/250	250	50	100
CR6108H	330	360	0.3	0.5	23	48	23	2500/250	250	45	90
CR6109H	350	380	0.3	0.5	23	48	23	2500/250	250	45	90
CR6110H	360	390	0.3	0.5	23	48	23	2500/250	250	45	90
CR6103H	380	470	0.4	0.7	20	42	20	2500/250	250	50	100
CR6111H	380	430	0.3	0.5	23	48	23	2500/250	250	45	90
CR6104H	400	500	0.4	0.7	20	42	20	2500/250	250	50	100
CR6112H	400	450	0.3	0.5	23	48	23	2500/250	250	45	90
CR6113H	415	455	0.3	0.5	23	48	23	2500/250	250	45	90
CR6114H	450	500	0.3	0.5	23	48	23	2500/250	250	45	90
CR6105H	470	570	0.4	0.7	20	42	20	2500/250	250	50	100
CR6115H	470	520	0.3	0.5	23	48	23	2500/250	250	45	90
CR6106H	512	698	0.5	0.9	19	40	19	2500/250	250	50	100
CR6116H	520	576	0.3	0.5	23	48	23	2500/250	250	45	90
CR6117H	576	638	0.3	0.5	23	48	23	2500/250	250	45	90
CR6107H	600	800	0.5	0.9	19	40	19	2500/250	250	50	100
CR6118H	600	750	0.4	0.7	23	48	23	2500/250	250	45	90
CR6120H	638	704	0.3	0.5	23	48	23	2500/250	250	38	76
CR6121H	698	806	0.4	0.7	23	48	23	2500/250	250	38	76
CR6119H	700	1000	0.5	0.9	19	40	19	2500/250	250	45	90
CR6122H	700	830	0.4	0.7	23	48	23	2500/250	250	38	76
CR6123H	700	850	0.4	0.7	23	48	23	2000/200	200	32	64
CR6201H	790	960	0.4	0.7	23	48	23	2000/200	200	32	64
CR6302H	850	1030	0.4	0.7	23	48	23	2000/200	200	32	64
CR6303H	900	1100	0.4	0.7	23	48	23	2000/200	200	32	64
CR6304H	960	1215	0.4	0.7	23	48	23	2000/200	200	32	64
CR6301H	1000	1400	0.5	0.9	19	40	19	2500/250	250	38	76
CR6305H	1000	1220	0.4	0.7	23	48	23	2000/200	200	32	64
CR6306H	1100	1300	0.4	0.7	23	48	23	2000/200	200	32	64
CR6307H	1200	1450	0.4	0.7	23	48	23	2000/200	200	32	64
CR6401H	1350	1850	0.4	0.7	19	40	19	2000/200	200	32	64
CR6402H	1400	1700	0.4	0.7	23	48	23	2000/200	200	32	64
CR6403H	1400	1600	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6404H	1500	1800	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6601H	1700	2100	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6701H	2000	2300	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6801H	2100	2600	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6802H	2300	2700	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6803H	2500	2900	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6804H	2700	3100	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6805H	2800	3300	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6806H	2900	3500	0.3	0.5	23	48	23	2000/200	200	25.4	50.8
CR6807H	3300	3800	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6808H	3400	4200	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6809H	3600	4300	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6901H	3900	4700	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6902H	4200	5200	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6903H	5000	6000	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6904H	5700	6800	0.3	0.5	23	48	23	500/50	50	25.4	50.8
CR6905H	6000	8000	0.3	0.5	23	48	23	500/50	50	25.4	50.8
