20W Termination Rating Selector/ Data Sheets

Banner

Part Number Frequency Range (MHz) Insertion Loss Isolation Return Loss Forward Power Peak/Avg Rev Power Package Outline PDF Data
Low High (dB) (dB) (dB) (W) (W) (mm)
SL3116F 330 360 0.6 48 23 1000/200 20 76
SL3117F 350 380 0.6 48 23 1000/200 20 76
SL3119F 360 390 0.6 48 23 1000/200 20 76
SL3120F 380 430 0.7 48 23 1000/200 20 76
SL3121F 400 450 0.7 48 23 1000/200 20 76
SL3122F 430 460 0.4 52 25 1000/200 20 76
SL3124F 450 500 0.6 48 23 1000/200 20 76
SL3125F 470 520 0.6 48 23 1000/200 20 76
SL3126F 520 576 0.6 48 23 1000/200 20 76
SL3128F 576 638 0.6 48 23 1000/200 20 76
SL3130F 638 704 0.6 48 23 1000/200 20 76
SL3132F 698 806 0.6 48 23 1000/200 20 76
SL3134F 700 830 0.7 48 23 1000/200 20 76
SL3136F 728 821 0.7 48 23 1000/200 20 64
SL3138F 790 960 0.7 48 23 1000/200 20 64
SL3218F 806 870 0.4 52 25 1000/200 20 64
SL3220F 830 890 0.4 52 25 1000/200 20 64
SL3222F 850 1000 0.7 48 23 1000/200 20 64
SL3223F 860 960 0.5 48 23 1000/200 20 50.8
SL3314F 1000 1200 0.7 48 23 1000/200 20 64
SL3318F 1100 1300 0.6 48 23 1000/200 20 50.8
SL3316F 1200 1420 0.7 48 23 1000/200 20 64
SL3320F 1200 1400 0.6 48 23 1000/200 20 50.8
SL3321F 1400 1600 0.6 48 23 1000/200 20 50.8
SL3412F 1500 1800 0.5 48 23 1000/200 20 50.8
SL3414F 1700 2100 0.7 48 23 1000/200 20 50.8
SL3410F 1710 1880 0.5 52 25 1000/200 20 50.8
SL3506F 1800 2000 0.5 52 25 1000/200 20 50.8
SL3508F 1800 2200 0.7 48 23 1000/200 20 50.8
SL3510F 1805 1990 0.6 48 23 1000/100 20 38
SL3604F 1900 2200 0.5 48 23 1000/200 20 50.8
SL3606F 1920 2170 0.5 52 25 1000/200 20 50.8
SL3608F 1920 2125 0.6 48 23 1000/100 20 38
SL3710F 2010 2300 0.6 52 25 1000/200 20 50.8
SL3806F 2200 2400 0.5 52 25 1000/200 20 50.8
SL3712F 2024 2286 0.6 48 23 1000/100 20 38
SL3818F 2200 2300 0.4 52 25 1000/100 20 38
SL3820F 2250 2650 0.5 48 23 1000/100 20 38
SL3816F 2300 2680 0.6 52 25 1000/200 20 50.8
SL3822F 2300 2700 0.5 48 23 1000/100 20 38
SL3824F 2470 2730 0.4 52 25 1000/100 20 38
SL3826F 2700 3300 0.6 48 23 1000/100 20 38
SL3828F 2900 3500 0.6 48 23 1000/100 20 38
SL3830F 3300 3800 0.5 48 23 1000/100 20 38



100W Termination Rating Selector/ Data Sheets

Banner

Part Number Frequency Range (MHz) Insertion Loss Isolation Return Loss Forward Power Peak/Avg Rev Power Package Outline PDF Data
Low High (dB) (dB) (dB) (W) (W) (mm)
SL3118F 330 360 0.6 48 23 1000/200 100 76
SL3103F 350 380 0.6 48 23 1000/200 100 76
SL3104F 360 390 0.6 48 23 1000/200 100 76
SL3105F 380 430 0.7 48 23 1000/200 100 76
SL3106F 400 450 0.7 48 23 1000/200 100 76
SL3123F 430 460 0.4 52 25 1000/200 100 76
SL3107F 450 500 0.6 48 23 1000/200 100 76
SL3108F 470 520 0.6 48 23 1000/200 100 76
SL3127F 520 576 0.6 48 23 1000/200 100 76
SL3129F 576 638 0.6 48 23 1000/200 100 76
SL3131F 638 704 0.6 48 23 1000/200 100 76
SL3133F 698 806 0.6 48 23 1000/200 100 76
SL3135F 700 830 0.7 48 23 1000/200 100 76
SL3137F 728 821 0.7 48 23 1000/200 100 64
SL3139F 790 960 0.7 48 23 1000/200 100 64
SL3217F 806 870 0.4 52 25 1000/200 100 64
SL3219F 830 890 0.4 52 25 1000/200 100 64
SL3221F 850 1000 0.7 48 23 1000/200 100 64
SL3213F 860 960 0.5 48 23 1000/200 100 50.8
SL3305F 1000 1200 0.7 48 23 1000/200 100 64
SL3317F 1100 1300 0.6 48 23 1000/200 100 50.8
SL3315F 1200 1420 0.7 48 23 1000/200 100 64
SL3309F 1200 1400 0.6 48 23 1000/200 100 50.8
SL3319F 1400 1600 0.6 48 23 1000/200 100 50.8
SL3411F 1500 1800 0.5 48 23 1000/200 100 50.8
SL3413F 1700 2100 0.7 48 23 1000/200 100 50.8
SL3405F 1710 1880 0.5 52 25 1000/200 100 50.8
SL3507F 1800 2000 0.5 52 25 1000/200 100 50.8
SL3509F 1800 2200 0.7 48 23 1000/200 100 50.8
SL3511F 1805 1990 0.6 48 23 1000/100 100 38
SL3603F 1900 2200 0.5 48 23 1000/200 100 50.8
SL3605F 1920 2170 0.5 52 25 1000/200 100 50.8
SL3607F 1920 2125 0.6 48 23 1000/100 100 38
SL3709F 2010 2300 0.6 52 25 1000/200 100 50.8
SL3817F 2200 2400 0.5 52 25 1000/200 100 50.8
SL3711F 2024 2286 0.6 48 23 1000/100 100 38
SL3821F 2200 2300 0.4 52 25 1000/100 100 38
SL3823F 2250 2650 0.5 48 23 1000/100 100 38
SL3819F 2300 2680 0.6 52 25 1000/200 100 50.8
SL3825F 2300 2700 0.5 48 23 1000/100 100 38
SL3827F 2470 2730 0.4 52 25 1000/100 100 38
SL3829F 2700 3300 0.6 48 23 1000/100 100 38
SL3831F 2900 3500 0.6 48 23 1000/100 100 38
SL3832F 3300 3800 0.5 48 23 1000/100 100 38
