Standard_20W_Drop_In_Isolator_Data_Table_05092013

Part Number	Frequency Range(MHz)		Insertion Loss	Isolation	Return Loss	Forward Power Peak/Avg	Rev Power	Package Outline
	Low	High	dB	dB	dB	(W)	(W)	(mm)
RFSL8409	800	2000	0.6	16	16	500/50	20	56
RFSL8407	800	2000	0.6	16	16	500/100	100	56
RFSL8401	1000	2000	0.5	19	19	500/50	20	56
RFSL8403	1000	2000	0.5	19	19	500/100	100	56
RFSL8501	1250	2500	0.5	19	19	500/50	20	56
RFSL8502	1250	2500	0.5	19	19	500/100	100	56
RFSL8703	1500	3000	0.5	19	19	500/50	20	38
RFSL8704	1500	3000	0.5	19	19	500/100	50	38
RFSL8705	1600	3200	0.5	19	19	500/50	20	38
RFSL8706	1600	3200	0.5	19	19	500/100	50	38
RFSL8707	1700	4200	0.5	17	17	500/50	20	38
RFSL8708	1700	4200	0.5	17	17	500/100	50	38
RFSL8901	2000	6000	1	13	13	500/50	20	38
RFSL8907	2000	6000	1	13	13	500/100	50	38
RFSL8801	2000	4000	0.5	20	20	500/50	20	38
RFSL8805	2000	4000	0.5	20	20	500/100	50	38
RFSL8806	2100	4200	0.5	20	20	500/50	20	38
RFSL8807	2100	4200	0.5	20	20	500/100	50	38
RFSL8808	2500	5000	0.5	19	19	500/50	20	38
RFSL8809	2500	5000	0.5	19	19	500/100	50	38
RFSL8812	2600	5200	0.5	19	19	500/50	20	38
RFSL8813	2600	5200	0.5	19	19	500/100	50	38
RFSL8902	3000	6000	0.5	20	20	500/50	20	25.4
RFSL8908	3200	6400	0.5	20	20	500/50	20	25.4
RFSL8909	3500	7000	0.5	20	20	500/50	20	25.4
RFSL8912	4000	8000	0.5	20	20	250/30	20	19
RFSL8915	4500	9000	0.5	20	20	250/30	10	19
RFSL8917	5000	10000	0.5	19	19	250/30	10	19
RFSL8918	5200	10400	0.5	19	19	250/30	10	19
RFSL8920	5500	11000	0.5	19	19	250/30	10	19
RFSL8921	6000	12000	0.5	19	19	250/30	10	19
RFSL8923	6500	13000	0.5	19	19	250/30	5	19
RFSL8925	7000	12400	0.5	21	21	250/30	5	19
RFSL8926	7000	14000	0.5	19	19	250/30	5	19
RFSL8928	7500	15000	0.5	19	19	250/30	5	19
