| Part Number | Frequency Range (MHz) |
Insertion Loss dB |
Isolation dB |
Return Loss dB |
Forward Power Peak/Avg |
Rev Power (W) |
IMD (dBc) |
Package Outline (mm) |
PDF Data | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Low | High | (W) | L | M | |||||||
| RFSL5104 | 728 | 768 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 |  |
| RFSL5105 | 728 | 768 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5202 | 869 | 894 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 | |
| RFSL5203 | 869 | 894 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5301 | 920 | 960 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 | |
| RFSL5302 | 920 | 960 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5501 | 1805 | 1880 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 | |
| RFSL5502 | 1805 | 1880 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5503 | 1805 | 1880 | 0.22 | 23 | 23 | 500/100 | 60 | 75 | 14.5 | 20.8 | |
| RFSL5504 | 1805 | 1880 | 0.22 | 23 | 23 | 500/100 | 20 | 75 | 14.5 | 17.8 | |
| RFSL5601 | 1930 | 1995 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 | |
| RFSL5602 | 1930 | 1995 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5603 | 1930 | 1995 | 0.22 | 23 | 23 | 500/100 | 60 | 75 | 14.5 | 20.8 | |
| RFSL5604 | 1930 | 1995 | 0.22 | 23 | 23 | 500/100 | 20 | 75 | 14.5 | 17.8 | |
| RFSL5701 | 2090 | 2190 | 0.22 | 23 | 23 | 500/200 | 80 | 75 | 25.4 | 31.8 | |
| RFSL5702 | 2090 | 2190 | 0.22 | 23 | 23 | 500/200 | 20 | 75 | 25.4 | 28.2 | |
| RFSL5703 | 2110 | 2170 | 0.22 | 23 | 23 | 500/100 | 60 | 75 | 14.5 | 20.8 | |
| RFSL5704 | 2110 | 2170 | 0.22 | 23 | 23 | 500/100 | 20 | 75 | 14.5 | 17.8 | |
| RFSL5801 | 2620 | 2690 | 0.22 | 23 | 23 | 500/100 | 60 | 75 | 14.5 | 20.8 | |
| RFSL5802 | 2620 | 2690 | 0.22 | 23 | 23 | 500/100 | 20 | 75 | 14.5 | 17.8 | |
