Single Sma Circulator Data Sheets

Part Number	Frequency Range MHz		Insertion Loss	Isolation	Return Loss	Forward Power Peak/Avg	Rev Power	Package Outline
	Low	High	(dB)	(dB)	(dB)	(W)	(W)	(mm)
RFCR6151	270	330	0.4	20	20	2500/250	250	50
RFCR6152	328	406	0.4	20	20	2500/250	250	50
RFCR6158	330	360	0.3	23	23	2500/250	250	45
RFCR6159	350	380	0.3	23	23	2500/250	250	45
RFCR6160	360	390	0.3	23	23	2500/250	250	45
RFCR6161	380	430	0.3	23	23	2500/250	250	45
RFCR6153	380	470	0.4	20	20	2500/250	250	50
RFCR6162	400	450	0.3	23	23	2500/250	250	45
RFCR6154	400	500	0.4	20	20	2500/250	250	50
RFCR6163	415	455	0.3	23	23	2500/250	250	45
RFCR6164	450	500	0.3	23	23	2500/250	250	45
RFCR6165	470	520	0.3	23	23	2500/250	250	45
RFCR6155	470	570	0.4	20	20	2500/250	250	50
RFCR6156	512	698	0.5	19	19	2500/250	250	50
RFCR6166	520	576	0.3	23	23	2500/250	250	45
RFCR6167	576	638	0.3	23	23	2500/250	250	45
RFCR6168	600	750	0.4	23	23	2500/250	250	45
RFCR6157	600	800	0.5	19	19	2500/250	250	50
RFCR6170	638	704	0.3	23	23	2500/250	250	38
RFCR6171	698	806	0.4	23	23	2500/250	250	38
RFCR6172	700	830	0.4	23	23	2500/250	250	38
RFCR6173	700	850	0.4	23	23	2000/200	200	32
RFCR6169	700	1000	0.5	19	19	2500/250	250	45
RFCR6251	790	960	0.4	23	23	2000/200	200	32
RFCR6352	850	1030	0.4	23	23	2000/200	200	32
RFCR6353	900	1100	0.4	23	23	2000/200	200	32
RFCR6354	960	1215	0.4	23	23	2000/200	200	32
RFCR6355	1000	1220	0.4	23	23	2000/200	200	32
RFCR6351	1000	1400	0.4	19	19	2500/250	250	38
RFCR6356	1100	1300	0.4	23	23	2000/200	200	32
RFCR6357	1200	1450	0.4	23	23	2000/200	200	32
RFCR6451	1350	1850	0.4	19	19	2000/200	200	32
RFCR6453	1400	1600	0.3	23	23	2000/200	200	25.4
RFCR6452	1400	1700	0.4	23	23	2000/200	200	32
RFCR6454	1500	1800	0.3	23	23	2000/200	200	25.4
RFCR6651	1700	2100	0.3	23	23	2000/200	200	25.4
RFCR6751	2000	2300	0.3	23	23	2000/200	200	25.4
RFCR6851	2100	2600	0.3	23	23	2000/200	200	25.4
RFCR6852	2300	2700	0.3	23	23	2000/200	200	25.4
RFCR6853	2500	2900	0.3	23	23	2000/200	200	25.4
RFCR6860	2700	2900	0.3	23	23	1000/100	100	19
RFCR6854	2700	3100	0.3	23	23	2000/200	200	25.4
RFCR6855	2800	3300	0.3	23	23	1000/100	100	19
RFCR6856	2900	3500	0.3	23	23	1000/100	100	19
RFCR6857	3300	3800	0.3	23	23	500/50	50	19
RFCR6858	3400	4200	0.3	23	23	500/50	50	19
RFCR6859	3600	4300	0.3	23	23	500/50	50	19
RFCR6951	3900	4700	0.3	23	23	500/50	50	19
RFCR6952	4200	5200	0.3	23	23	500/50	50	19
RFCR6953	5000	6000	0.3	23	23	500/50	50	19
RFCR6956	5400	5900	0.3	22	22	250/25	25	12.7
RFCR6954	5700	6800	0.3	23	23	500/50	50	19
RFCR6957	5700	6800	0.3	22	22	250/25	25	12.7
RFCR6955	6000	8000	0.3	23	23	500/50	50	19
RFCR6958	6400	7200	0.3	22	22	250/25	25	12.7
RFCR6959	6550	7850	0.3	22	22	250/25	25	12.7
RFCR6960	7200	8400	0.3	22	22	250/25	25	12.7
RFCR6961	7500	9000	0.3	22	22	250/25	25	12.7
RFCR6962	8000	10000	0.3	22	22	250/25	25	12.7
RFCR6963	9000	11500	0.3	22	22	250/25	25	12.7
RFCR6964	10000	12500	0.3	22	22	250/25	25	12.7
RFCR6965	11000	14000	0.3	22	22	250/25	25	12.7
RFCR6966	11500	15000	0.3	22	22	250/25	25	12.7
RFCR6967	13000	16000	0.3	22	22	250/25	25	12.7
RFCR6968	14000	16500	0.4	22	22	250/25	25	12.7
RFCR6969	15000	18000	0.4	22	22	250/25	25	12.7
RFCR6970	17000	20000	0.4	22	22	250/25	25	12.7
