ThinPak Single Circulators

Part Number	Frequency Range (MHz)		Insertion Loss dB	Isolation dB	Return Loss dB	Forward Power Peak/Avg	Rev Power (W)	Package Outline
	Low	High	(dB)	(dB)	(dB)	(W)	(W)	(mm)
RFCR3116	330	360	0.35	23	23	1000/200	200	38
RFCR3102	350	380	0.35	23	23	1000/200	200	38
RFCR3103	360	390	0.35	23	23	1000/200	200	38
RFCR3104	380	430	0.4	23	23	1000/200	200	38
RFCR3105	400	450	0.4	23	23	1000/200	200	38
RFCR3106	430	460	0.25	25	25	1000/200	200	38
RFCR3107	450	500	0.35	23	23	1000/200	200	38
RFCR3108	470	520	0.35	23	23	1000/200	200	38
RFCR3109	520	576	0.35	23	23	1000/200	200	38
RFCR3110	576	638	0.35	23	23	1000/200	200	38
RFCR3111	638	704	0.35	23	23	1000/200	200	38
RFCR3112	698	806	0.35	23	23	1000/200	200	38
RFCR3113	700	830	0.4	23	23	1000/200	200	38
RFCR3114	728	821	0.4	23	23	1000/200	200	32
RFCR3115	790	960	0.4	23	23	1000/200	200	32
RFCR3201	806	870	0.25	25	25	1000/200	200	32
RFCR3202	830	890	0.25	25	25	1000/200	200	32
RFCR3203	850	1000	0.4	23	23	1000/200	200	32
RFCR3204	860	960	0.3	23	23	1000/200	200	25.4
RFCR3302	1000	1200	0.4	23	23	1000/200	200	32
RFCR3304	1100	1300	0.35	23	23	1000/200	200	25.4
RFCR3303	1200	1420	0.4	23	23	1000/200	200	32
RFCR3305	1200	1400	0.35	23	23	1000/200	200	25.4
RFCR3306	1400	1600	0.35	23	23	1000/200	200	25.4
RFCR3406	1500	1800	0.3	23	23	1000/200	200	25.4
RFCR3407	1700	2100	0.4	23	23	1000/200	200	25.4
RFCR3404	1710	1880	0.3	25	25	1000/200	200	25.4
RFCR3501	1800	2000	0.3	25	25	1000/200	200	25.4
RFCR3502	1800	2200	0.4	23	23	1000/200	200	25.4
RFCR3503	1805	1990	0.35	23	23	1000/100	100	19
RFCR3603	1900	2200	0.3	23	23	1000/200	200	25.4
RFCR3601	1920	2170	0.3	25	25	1000/200	200	25.4
RFCR3604	1920	2125	0.35	23	23	1000/100	100	19
RFCR3701	2010	2300	0.35	25	25	1000/200	200	25.4
RFCR3806	2200	2400	0.3	25	25	1000/200	200	25.4
RFCR3702	2024	2286	0.35	23	23	1000/100	100	19
RFCR3808	2200	2300	0.25	25	25	1000/100	100	19
RFCR3809	2250	2650	0.3	23	23	1000/100	100	19
RFCR3807	2300	2680	0.35	25	25	1000/200	200	25.4
RFCR3810	2300	2700	0.3	23	23	1000/100	100	19
RFCR3811	2470	2730	0.25	25	25	1000/100	100	19
RFCR3812	2700	3300	0.35	23	23	1000/100	100	19
RFCR3813	2900	3500	0.35	23	23	1000/100	100	19
RFCR3814	3300	3800	0.3	23	23	1000/100	100	19
