Part Number Frequency Range
(MHz)		 Insertion Loss
dB		 Isolation
dB		 Return Loss
dB		 Forward Power Peak/Avg
(W)		 Rev Power
(W)		 IMD
(dBc)		 Package Size
(mm)		 PDF Data
Low High L W
SL2134-FA30 400 450 0.6 48 23 1000/200 100 76 45
SL2161-FA30 415 455 0.5 48 23 1000/200 100 76 45
SL2122-FA30 430 460 0.4 55 25 1000/200 100 76 45
SL2136-FA30 450 500 0.5 48 23 1000/200 100 76 45
SL2138-FA30 470 520 0.5 48 23 1000/200 100 76 45
SL2156-FA30 700 830 0.5 48 23 1000/200 100 63.6 38
SL2157-FA30 728 756 0.4 55 25 1000/200 100 75 63.6 38
SL2158-FA30 728 821 0.5 48 23 1000/200 100 75 63.6 38
SL2124-FA30 728 756 0.4 55 25 1000/200 100 75 50.8 31.8
SL2160-FA30 790 960 0.5 48 22 1000/200 100 63.6 38
SL2232-FA30 790 960 0.6 42 20 1000/200 100 75 50.8 31.8
SL2159-FA30 791 821 0.4 55 25 1000/200 100 75 63.6 38
SL2126-FA30 791 821 0.4 55 25 1000/200 100 75 50.8 31.8
SL2225-FA30 806 870 0.4 55 25 1000/200 100 75 50.8 31.8
SL2223-FA30 830 890 0.4 55 25 1000/200 100 75 50.8 31.8
SL2254-FA30 860 960 0.5 48 25 1000/200 100 63.6 38
SL2230-FA30 860 960 0.5 48 23 1000/200 100 75 50.8 31.8
SL2208-FA30 869 894 0.4 55 25 1000/200 100 75 50.8 31.8
SL2228-FA30 885 920 0.4 55 25 1000/200 100 75 50.8 31.8
SL2319-FA30 900 930 0.4 55 25 1000/200 100 75 50.8 31.8
SL2308-FA30 920 960 0.4 55 25 1000/200 100 75 50.8 31.8
SL2341-FA30 1000 1200 0.5 48 23 1000/200 100 63.6 38
SL2344-FA30 1200 1400 0.4 55 25 1000/200 100 63.6 38
SL2327-FA30 1200 1400 0.5 48 23 1000/200 100 50.8 31.8
SL2429-FA30 1500 1800 0.5 48 23 1000/200 100 63.6 38
SL2434-FA30 1600 1650 0.4 55 25 1000/100 100 38 25.4
SL2525-FA30 1700 2100 0.5 48 23 1000/200 100 63.6 38
SL2411-FA30 1700 2100 0.5 48 23 1000/200 100 50.8 31.8
SL2405-FA30 1710 1785 0.4 55 25 1000/200 100 75 50.8 31.8
SL2435-FA30 1710 1785 0.4 55 25 1000/100 100 75 38 25.4
SL2526-FA30 1800 2200 0.5 48 23 1000/200 100 63.6 38
SL2527-FA30 1800 2000 0.45 55 25 1000/200 100 50.8 31.8
SL2507-FA30 1805 1880 0.4 55 25 1000/200 100 75 50.8 31.8
SL2528-FA30 1805 1880 0.4 55 25 1000/100 100 75 38 25.4
SL2529-FA30 1805 1990 0.45 48 23 1000/100 100 75 38 25.4
SL2615-FA30 1880 1930 0.4 55 25 1000/200 100 75 50.8 31.8
SL2530-FA30 1880 1930 0.4 55 25 1000/100 100 75 38 25.4
SL2619-FA30 1920 2170 0.45 55 25 1000/200 100 75 50.8 31.8
SL2617-FA30 1930 1995 0.4 55 25 1000/200 100 75 50.8 31.8
SL2610-FA30 1930 1995 0.4 55 25 1000/100 100 75 38 25.4
SL2704-FA30 2090 2190 0.4 55 25 1000/200 100 75 50.8 31.8
SL2715-FA30 2130 2280 0.4 55 25 1000/200 100 75 50.8 31.8
SL2717-FA30 2010 2300 0.45 55 25 1000/200 100 50.8 31.8
SL2735-FA30 2090 2190 0.4 55 25 1000/100 100 75 38 25.4
SL2736-FA30 2130 2280 0.4 55 25 1000/100 100 38 25.4
SL2822-FA30 2300 2680 0.45 55 25 1000/200 100 50.8 31.8
SL2835-FA30 2470 2730 0.4 55 25 1000/100 100 75 38 25.4
SL2836-FA30 2490 2690 0.4 55 25 1000/100 100 75 38 25.4
SL2838-FA30 2620 2690 0.4 55 25 1000/100 100 38 25.4
SL2841-FA30 2900 3100 0.4 55 25 1000/100 100 38 25.4
